ANSI A156.2, Grade 3

Reversible leverset

Door Prep: 2-⅛” Cross Bore; 1” Edge

5-pin KW keyway; solid brass cylinder

Latch: 1” face, ¼” radius corner, adjustable

Strike: 2-¼” x 1-¾” full-lip, ¼” radius corner

Satin Nickel (US15/619)

ANSI A156.2, Grade 3

Door Prep: 2-⅛” Cross Bore; 1” Edge

5-pin KW keyway; solid brass cylinder

Latch: 1” face, ¼” radius corner, adjustable

Strike: 2-¼” x 1-¾” full-lip, ¼” radius corner

Dark Bronze (US12P/716)

Satin Nickel (US15/619)

Antique Nickel (US15A/620)

ANSI A156.2, Grade 3

Door Prep: 2-⅛” Cross Bore; 1” Edge

5-pin KW keyway; solid brass cylinder, zinc die-cast housing

Latch: 1” face, ¼” radius corner, 2-⅜” backset

Strike: 2-¼” x 1” rectangular, ¼” radius corner

Available in Single Cylinder, Double Cylinder, One-Sided and One-Sided w. Cover

Oil Rubbed Bronze (US10B/613)

Dark Bronze (US12P/716)

Satin Nickel (US15/619)

Antique Nickel (US15A/620)

Satin Chrome (US26D/626)

Polished Brass (US3/605)

Satin Stainless Steel (US32D/630)

Antique Brass (US5/609)

Lifetime Polished Brass (USL03/505)
